CAN Chevrolet CMP Field Artillery Tractor Cab 11 + Limber – lot 229

All our auctions are behind registration and login conditions.
Please

Current bid: 17,000.00

Canadas support for repowering the Commonwealth troops in the early days of WW-II

DESCRIPTION
This fantastic and highly desirable Lot consist of a Class A restored 1940 Chevrolet Field Artillery Tractor (FAT) and its matching 1939 Limber.
But be aware: the also matching 1940 Quick Fire 25 Pounder Gun will be offered in this auction as a separate lot (Lot 0231).
And……. if you want to go ‘all the way’ finally a 17 Pounder Anti-Tank Gun (Lot 243) as being the whole grail of British gun design and never been on the market since the last 5 years will be a fantastic asset to complete this set!

The Field Artillery Tractor (FAT) was a four-wheel-drive towing vehicle used with the 25 Pounder Field Gun and the 17 Pounder Anti-Tank Gun during the Second World War. Under the vehicle is a very heavy winch for moving the gun or to winch the vehicle in bad terrain.
Ford and General Motors in Canada produced over 22,000 FATS during the war.
This FAT is a very rare survivor of the Chevrolet 8440/CGT series. To be exact, an early 1940 example Model 84-40 of the variant known as a FAT-1 with a 7A2 body and No.11 cab produced by The General Motors of Canada Limited, Oshawa Walkerville Regina Works Vehicle was delivered in TBRA Trim and paint F.C. 98. It was fully restored in a 4-year restoration period by a team of professionals.

The Artillery Trailer, or “Limber,” was used to carry ammunition and equipment for the gun. The Limber carried 32 rounds of ammunition for the 25 Pdr Field Gun or the 17 Pdr Anti-Tank Gun, along with extra fuses. The personal kit of the Gunners was under a tarp on the front of the trailer. The Limber was never that popular as it made backing up very difficult. A Limber had been required for centuries to bear the weight of the gun to allow horses to pull, but it was no longer necessary with vehicles. Therefore, use of Limbers ended after the 25 Pdr went out of service, thus also the end of an era! Since then, ammunition and stores have simply been carried in the towing vehicle.

HISTORY
In 1935, two years after the founding of the Third Reich in Germany, the British War Office entered into discussions with Canada as to that country’s potential for the production of war material. Initial talks only resulted in what have been termed ‘educational contracts’ relating to, for instance, Bren light machine guns and 25-pounder field guns. Canada’s automotive industry did not immediately benefit. However, Canada’s Ministry of Militia and Defense subsequently sought the aid of the auto manufacturers in designing vehicles for military service and what could now be termed the first Canadian Military Pattern (CMP) prototype emerged in 1937. Designed by Syd Swallow, an engineer employed by the Ford Motor Company of Canada, it was basically a ‘Canadianized’ version of a standard British 15cwt.

When the British were driven into the sea at Dunkirk in 1940, many vehicles remained behind in France. They were already in France and could no longer be brought back so quickly. It was therefore necessary to make up for these shortfalls as quickly as possible. The British and Commonwealth army grew explosively through the war and needed many vehicles. Canada was in a good position to help due to the presence of a large and modern auto industry. Even before the outbreak of war there was close cooperation between British and Canadian institutions and specifications for military vehicles had already been established. The use of existing American technology and extensive Canadian standards in construction offered opportunities to quickly produce large numbers of vehicles.
2.1 Canadian military vehicle design
At this distance it might seem odd that the Canadian authorities should contract manufacturers (General Motors of Canada also subsequently produced a 15cwt prototype) with U.S.-based parent companies to design a vehicle based on British standards.
However, the U.S. was not at war at that time and Canada, as a member of the Commonwealth, would be fighting alongside Britain and it was logical to adopt British standards. In retrospect, we may think differently. Anyway, in 1939 it became policy that the design of Canadian military vehicles should be based on that of the British Army, and the Ford Company of Canada and General Motors Canada were asked by the Canadian Ministry of National Defense to collaborate in the design and development of a series of MVS to British standards. Each company would retain its own powerplant, chassis and cooling system but would otherwise seek compatibility as far as possible.

Getting FAT
At first these vehicles were referred to as Department of National Defense (DND) Pattern, but as users other than the Canadian Army began to order in large quantities the blanket designation was altered to Canadian Military Pattern (CMP).
Production commenced in 1940 with fewer than 15,000 CMPs being manufactured in the first year, mainly for domestic use. However, the numbers rapidly increased as orders -particularly from Britain- flooded in.
Sources differ, but in the region of 400,000 CMPs had been produced by late 1945, a sizeable percentage of the total number of military vehicles produced in Canada during WW2 which, if you include Commercial and Modified Conventional types (i.e. militarized commercial designs) and armored vehicles, reached in excess of 850,000! A small number of CMP vehicles were produced in Australia, New Zealand, India, Egypt and England.

In accordance with CMP specifications, all vehicles were made with right-hand drive, although in Canada all vehicles were left-hand drive. The CMP specification proved to be versatile and formed the basis for a wide variety of different trucks and armored vehicles. However, there was one demand that the Canadians were not too happy about. The English demanded that the dashboard should be thirteen inches from the front axle. That was quite a switch, but in the end it was not so odd. This caused the engine to sit half in front of the cabin. This made it a compact vehicle with more cargo space available within the total length compared to the American vehicles.
Before we get pointlessly bogged down in production figures and design requirements it’s worth noting that, according to one reliable source, 22,891 of the total CMPs manufactured were 4×4 field artillery tractors (FAT). These were produced by Ford as the G2910/FGT and by General Motors as the Chevrolet 8440/CGT. To explain, CMP FATS were produced in six variants starting with the FAT-1 fitted with the (notoriously cramped) No.11 cab, and continuing via the slightly improved No.12 cab-equipped FAT-2 (1941) to the FATS 3 to 6, all of which had the distinctive No.13 cab (1943) with its reverse-sloped windscreen, CMP FATS were patterned on field artillery tractors made in Britain by most notably, Morris-Commercial but also Guy and Karrier which we tend to refer to as ‘Quads.
Sitting on a 101in wheelbase chassis, the Chevrolet 8440/CGT was powered by the company’s own 216 engine; a straight- six engine of 3,542cc (216 cubic inch) capacity. With a maximum of 85bhp on tap, power was transmitted to all of the rear wheels via a four-speed gearbox and two-speed transfer box.
Most importantly, a power winch was located above the rear axle. Of course, Ford’s version duplicated those specifications but instead utilized Ford’s ubiquitous flathead V8 which, with a few more cubic inches available, managed an extra 10bhp.

Extensive restoration
Relatively a very few FATs have survived since WW-II. During wartime they were hard worked. After the war, those that entered the civilian market through surplus auctions were again hard worked! Of many the rear body was removed and a jib, which had to work with the existing winch, or a cargo platform was installed. In these days an ex-army FAT made for a cheap, cheerful, and undeniably rugged (breakdown) truck.
So, although many FATs could find work in civilian applications, which would have ensured short-term survival, this ultimately resulted in many being scrapped.

The current owner purchased this FAT as a restorable project on 21-08-2002. One evening in 1999 he met Eddy Dieffenbach, the son of the famous Belgian collector Johan Dieffenbach. Eddy was in the process of selling his late father’s collection. The current owner was actually looking for a Dodge Command, but Eddy said: “If you’re really looking for something special, I have something really nice for you here, a Chevrolet HUP”. It clicked well with Eddy and eventually more vehicles from Johan’s collection ended up with the current owner after the HUP.

This was one of the last that the current owner managed to purchase from the Dieffenbach family. All vehicles that the current owner owns or has owned have been perfectly restored and ready to drive away. Actually, just like the old days with Johan Dieffenbach. However, that was not the case with this Chevrolet. Johan hadn’t got around to that anymore. Through documentation research, the current owner discovered that it is a special vehicle; a Chevrolet Field Artillery Tractor Cab 11. You can apparently see that it is a Cab 11 by the closed roof. In the Cab 12, the roof is covered with a hood that can be opened if it gets too hot in the cab.
The purchase also included the matching original Limber ammunition trailer and a 25-pounder gun which will be auctioned by Tracks & Trade as well.

Further investigation revealed that Johan had purchased the Chevrolet in England. They had already started the restoration, but not in the right way. The back of the body consisted of a few flat stable plates with the hatches on top. Without a hole underneath! The still original parts of the body were so rotten that they had to be replaced as part of the restoration.
The current owner was at a loss for words, but fortunately he had a good friend who was a professional sheet metal worker. He had a good idea: “Then we just make a 100% copy of the cabin”.
Easier said than done because the old cabin could no longer serve as a guideline, as there was nothing left in the back.

A lot of research was needed, looking at a many of old photos and especially a lot of visits to Mr Dirk Leeghwater (LwD Parts from Broek op Langedijk in the Netherlands). He also had such a cabin and is also a great connoisseur of Canadian vehicles. Fortunately, the old one was able to supply important hooks, brackets, and locks for the doors and therefore the new cab has become an exact copy of the old one, but then as it should be with all the shutters and the cupboards. At the same time, the rest was taken care of. Everything has been apart. All iron parts sandblasted and metallized.

This is the application of a thin layer of zinc by means of a flame sprayer. Then adhesive primer and a green lacquer (SCC 15).
The entire driveline has also been overhauled; axles, differentials, gearboxes, winch, engine, steering box, and so on. All seats were also reupholstered. In the end everything was put back together and finally completely repainted one more time.
The result is amazing, it’s just a brand-new vehicle! Only the tires that were under it looked nothing like it. They were too small compared to the large wheel arches. After a long search, the current owner found the right rim size with a NATO profile at a dealer, but they were also too small. Finally, he was able to exchange those tires for the right size and dimensions

Over 1.800 hrs. have been invested in the period 2002-2006. In that year the FAT was ready and received a Belgian road license.

Chevrolet’s straight-six: power to the people
Chevrolet’s straight-six engine entered the market in 1929 and was not completely withdrawn from U.S. production until 1990. In fact, the straight-six was the company’s only one until 1955, when a small-block V8 was introduced as an option. In this FAT still the original WW-II engine which was fully refurbished. Due to its condition a full overhaul was not necessary.

Limber
The Artillery Trailer, or “Limber,” was used to carry ammunition and equipment for the gun.
The Limber carried 32 rounds of ammunition for the 25 Pdr Field Gun or the 17 Pdr Anti-Tank Gun, along with extra fuses. The personal kit of the Gunners was under a tarp on the front of the trailer.
The Limber was not that popular as it made backing up very difficult. A Limber had been required for centuries to bear the weight of the gun to allow horses to pull, but it was no longer necessary with vehicles. The use of Limbers ended after the 25 Pdr went out of service. Since then, ammunition and supplies were simply carried in the towing vehicle.

This Limber is in great condition. It comes as indicated in the pictures accompanying this brochure.
On the left side all original ammo boxes are still there. On the right the ammo boxes are missing.

Location: & Collection

Current location of this object is B-2300 Turnhout, Belgium
Local collection is available for this lot.

Depending on the destination the Buyer shall obtain an International Import Certificate / End User Certificate. Some of the items listed in the auction may require special licenses or permits or existing documents must be prepared for export. If this is relevant, Tracks & Trade will take care of this for you, with the applicable costs being passed on to the successful bidder
Please email [email protected] if you have any questions or concerns.

No item will be allowed to be collected without 100% of all legal requirements being fulfilled.



Margin / VAT

This object is offered by Tracks & Trade pursuant to consignment sale on behalf of a private individual. Therefore, the margin scheme will be applicable, so no sales tax (VAT) over the hammer price will be applicable. For more info see General Conditions of Sale Article 9.

Buyer’s Premium

On all Lots a Commission or buyer’s premium (amounting 16,5%) is charged. Over this buyer’s premium 21% sales tax (VAT) will be applicable.



Inspection(s)

Inspections dates are listed in Colophon page and are conducted under following conditions:

  • Inspections will be strictly maximum 1 hour long escorted inspections,
  • Maximum of 3 customers per escorted tour,
  • Customers must book in prior to inspection,
  • Inspection times are 9am 10am 11am 1pm 2pm 3pm 4pm,
  • Please note that these inspections might be performed at several locations,
  • Inspections for a longer period or outside these hours can be organized for a refundable fee. (Refundable off purchase price of Auction lot).



To make a booking please reply to [email protected] at least 48 hours before the inspection with the following details:

Full Name(s) and contact details and phone number of the people that are coming to inspect. The LOT number(s) and Auction Name that you wish to inspect (items are stored on several locations, and we will need to retrieve them prior to your arrival).



Parts, accessories, and militaria

The batches of spare parts, various accessories and militaria are stored in the best conditions but are sold as-is and delivered without any guarantee of functioning.



Vehicles and vehicle related equipment such as

Cars, motorcycles, trucks, cannons or howitzers, armored vehicles, and tanks are sold in as-is condition, without guarantee and with or without registration (see description).



Collection

Parts, accessories, and militaria

The collection of the lots, subject to payment, starting are by appointment only, date is listed in the Colophon page.

Vehicles

Vehicles can be picked up, subject to payment, starting are by appointment only, date is listed in the Colophon page.
Handling costs for the removal of the vehicles will, when applicable, be applied at cost.

Arms & weapons

The Auction House will not supply ANY item unless the correct paperwork and licensing – if needed – have supplied in full.

If required and applicable (fire)arms can be made inoperable or permanently disabled by BAIV in The Netherlands as being a licensed Arms & Weapons Dealer Registration Nr. NL20191618779. In this case all relevant cost will be charged to the Buyer in addition and have to be paid in advance in full. Collection by appointment only!



Delivery and Storage

Removal of lots must be completed by the date listed on the Colophon page, after full payment and 100% coverage of all legal requirements.
No storage fees will be applicable until that date.

Lots not picked up by Buyers will be returned to secure storage at Buyer’s expense. In this case storage fees will be applied as follows :

  • Parts & accessories: € 25,- / lot / week
  • Cars and motorcycles: € 50,- / lot / week
  • Armored vehicles, tanks, cannons etc. € 75,- / lot / week

Above mentioned storage fees are excluding VAT.





General Conditions of Sale

General Conditions of Sale Version 2.0 dated 29-04-2022 are applicable


Bids on internet

The live auction will be broadcast on: www.aution.tracksandtrade.com

  1. Register for the auction (log in or create an account)
  2. Bid live.

Please use a computer to follow the live auction!



Others

If any item listed causes offence, or is not correctly or incompletely described, please advise us immediately and we will address your concerns.

Please note this auction date may change due to unforeseen circumstances.

Colophon

IMPORTANT DATES

Bidding Open: Saturday January 7th 2023

Inspection option 1: Friday January 27th 2023

Inspection option 2: Friday February 10th 2023

Bidding ends: Saturday March 11th 2023;

Amsterdam NL (CET):       04:00 PM (16:00)

London:                              03:00 PM (15:00)

New York USA:                   10:00 AM (10:00)

Sydney AUS:                      02:00 AM (02:00) Sunday February 19th

Collection of Lots starts on Monday March 27th 2023

Collection end date: Friday April 21st 2023
after this date storage costs will be applicable

CMP Field Artillery Tractor (FAT)

Description CMP FAT (Field Artillery Tractor) Quad
Model Chevrolet 8440/CGT Tractor, 4×4, Field Artillery (FAT-1) with a 7A2 body and No.11 in TBRA Trim
Color F.C. 98
Manufacturer General Motors of Canada Limited
Production figures Ford and General Motors in Canada produced over 22,000 FATS during WW-II
Net Weight 10,880 lbs. (4.935 kg.)
Gross weight 13,200 lbs. (5.987 kg.)
Crew 1 (one) driver and 5 (five) passengers
Engine

Chevrolet, straight 6-cyl 216 cubic inch (3,54 lt.) petrol engine

85 bhp (63 kW) @ 3,400 rpm

Transmission Manual operated gearbox 4 forward, 1 reverse, front wheel drive & high / low gear
Suspension Beam axles on leaf springs
Max. speed 45 miles/hour (74 kilometers/hour)
Dimensions Length: 169 in             (4,29 m)
Width:  90 in               (2,28 m)
Height: 96 in               (2,44 m)
Wheelbase 101 in                           (2,56 m)
Electrical installation 6 Volt
Armament Non
Permit(s) Non
Documentation Non
Date of production September 15 1940 (09-15-1940)
VIN Nr. 0844002482
Canedian registration CH421755
Road registration Belgium road registration (OBP 771)
Remarks Class A restored

Trailer Artillery or “Limber”

Description Trailer Artillery or “Limber”
Model Model 27 Mk I/L/
Manufacturer M-C.C.&W. Co Ltd
Color SCC 15 (Standard Camouflage Colour 15)
Weight Approx.. 1,870 lbs. (848 kg)
Dimensions

Length: 10 ft. 9 in      (3,27 m)

Width:    6 ft. 11 in      (2,11 m)

Height    4 ft. 0 in      (21 cm)

Electrical installation n.a.
Permit(s) n.a.
Documentation non
Year of Production 1939
Serial Nr. / Registration 5580
Remarks

The Limber carried 32 rounds of

ammunition for the 25 Pdr Field Gun







Raymund van Riel

Collector since 1977 and restoration expert since 1991

Due to my experience with and knowledge of Military Vehicles from the WW-II period, I am often asked to assess the originality of such a vehicle. In these cases the entire vehicle is examined by me in individual sections on originality. This step-by-step methodology finally results in an overall rating of the entire vehicle.

In 2005 I visited the current owner of this Chevrolet FAT, Cab 11 for an assessment of some of his other military vehicles. It was impressed that all vehicles from his collection were properly restored according to the proper standards and all in good running condition.

At that moment the Chevrolet FAT was still under restoration, but it certainly had my attention and the owner promised me that he would invite me when the restoration was finished. In 2008 I got an invitation for another visit. As a co-editor for a magazine, I decided to grasp the opportunity to write an article about this very unique Chevrolet.

I was overwhelmed; after the restoration, this was brought back to “new” ex-factory conditions but still highly original. This means that the almost all parts as being used during the restoration were actually dated from the correct period during WW-II. Even the rear part of the superstructure, which was too far gone to be restored, has being newly produced against the correct factory specifications! During this process, all parts of the original body, that were not irreparable were re-used, such as fixtures, hinges, and mounting brackets.

Besides the fact that it is and remains a special vehicle, the combination of the truck, limber and 25 Pdr. was reason for me to dedicate a nice article to it at that time.

I congratulate the new owner of this beautiful and very special unit of military cultural heritage and hope it finds a good new home.

Tilburg the Netherlands December 2022

Experts estimated value (Chevrolet FAT, Cab 11 and Limber):  between  € 32.500,- and € 37.500,- (May 2022)
